SCM Minimax S 41ES

Thicknesser

To get a quote or for further information please contact us on:

Email us
  • Features

    • Optional 'Xylent' cutter block
  • Description

    High technology at a competitive price in a thicknessing planer for demanding craftsmen and carpenters. Optimal planing with minimal effort, thanks to the 95 mm diameter cutter block  and 4 knives. For an impeccable finish the pressure of the thicknesser feed rollers can be adjusted according to the type of wood machined. The roller infeed has a helicoidal profile to guarantee firm and constant work piece feed, while the outfeed roller in sandblasted steel maintains the perfect post-processing finishing. For a maximum long lasting stability the cast iron thicknessing table lifts on 4 spindles with trapezoidal threads dust protected.

    Optional ‘Xylent’ cutter block available. The 3 spiralknives give an exceptional finish. Reduced noise during machining provides a more comfortable working environment. It also improves the dust extraction due to the production of very small chips. Each cutter has 4 tips which can be rotated into the cutting position when worn. Therefore increasing the production life of the cutter block before knives require replacement.

  • Specification

    • Working width 410 mm
    • Cutterblock diameter 95 mm
    • Dimension of standard knives 410 x 30 x 3
    • Max. stock removal 5 mm
    • Thicknessing table dimensions 410 x 775 mm
    • Feed speed on thicknesser 6/ 12 (m/min)
    • Min. / max. working height 3/ 240 mm
    • Three-phase motors 5 kW
  • Literature

  • Disclaimer

    Our suppliers have a policy of continuous product development and improvement, specifications are therefore subject to change without notice. We can accept no liability for discrepancies in specifications or illustrations contained in our publications or the publications of our suppliers.
