SCM Minimax ME 20
Edgebander
- Work table dimensions 1950 x 180 mm
- Min. x max. thickness of rolled edges 0.4 x 2
- Max. thickness of edges in strips 5 mm
- Min. x max. panel height 12 x 50 mm
SCM Minimax ME 22
Edgebander
- Work table dimensions 2600 x 530 mm
- Min. ÷ max. thickness of rolled edges 0.4 x 2 mm
- Max. thickness of edges in strips 5 mm
- Min. x max. panel height 12 x 50 mm
SCM Minimax ME 28T
Edgebander
- Work table dimensions 2800 x 570 mm
- Min. x max. thickness of rolled edges 0.4 x 3 mm
- Max. thickness of edges in strips 5 mm
- Min. x max. panel height 12 x 50 mm
SCM Minimax ME 35
Edgebander
- Work table dimensions 3000 x 525 mm
- Min. x max. thickness of rolled edges 0,4 x 3 mm
- Max. thickness of edges in strips 5 mm
- Min. x max. panel height 8 x 50 mm
SCM Minimax ME 40
Edgebander
- Work table dimensions 3465 x 710 mm
- Min. x max. thickness of rolled edges 0.4 x 3 mm
- Max. thickness of edges in strips 5 mm
- Min. x max. panel height 8 x 50 mm
SCM Minimax ME 25
Edgebander
- Work table dimensions 2600 x 530 mm
- Min. x max. thickness of rolled edges 0.4 x 3 mm
- Max. thickness of edges in strips 5 mm
- Min. x max. panel height 12 x 50 mm
CEHISA Mykro
Edgebander
- Edging material thickness 0.4 - 2 mm
- Panel thickness 8 - 50 mm
- Panel length 120 - unlimited
- Panel width 75 - unlimited
CEHISA Flexy
Edgebander
- Edging material thickness 0.4 - 2 mm
- Panel thickness 8 - 50 mm
- Panel length 120 mm - unlimited
- Panel width 75 mm - unlimited (60 mm option)
CEHISA Compact
Edgebander
- Edging material thickness 0.4 - 3 mm
- Solid edging thickness 5 mm (manually fed)
- Panel thickness 8 - 60 mm
- Panel length 120 mm - unlimited
CEHISA PRO
Edgebander
- Edging material thickness 0.4 - 3 mm
- Solid edging thickness 8 mm (auto feed option)
- Panel thickness 8 - 60 mm
- Panel length 120 mm - unlimited
CEHISA Avant
Edgebander
- Edging material thickness 0.4 - 3 mm
- Solid edging thickness 15 mm (with auto feed)
- Panel thickness 8 - 60 mm
- Panel length 120 mm - unlimited
CEHISA EP-C3
Edgebander
- Work piece thickness 8 - 50 mm
- Edging thickness 0.4 - 3 mm
- Motor NA
- Air pressure requirement 6 - 7 bar
The perfect introduction to professional edgebanding
Space saving design with reliable performance at an entry level price edgebanding machine. The CEHISA Flexy is available with pre-milling and corner rounding to ensure your product competes at the highest level. The DUO-MELT glue unit (available on all models) allows the use of both EVA and PUR glue technology.
Complete performance with increased working capacity
Designed for furniture manufactures requiring full edge processing. With minimal space requirements the CEHISA Compact combines versatility and ease of use to deliver consistently high performance results. An intuitive full colour touch screen positioned at the infeed keeps operation simple.
High production, automation and finish
With increased feed speeds and automatic program selection the CEHISA Pro and flag ship Avant models are designed for ultimate processing efficiency meeting the highest demands of quality, durability and flexibility. The optional Air-Jet system for zero-glue line performance produces a seamless workpiece with a flawless appearance. Options for automatic unit adjustment for different tape thicknesses is available where frequent quick change overs are required.
Work with coiled and solid edging
Depending on the model of edgebander, solid lipping edging can be applied up to 15mm, as well as coiled melamine, PVC and veneer up to 3mm. Each model features a CNC machined chassis and pressure beam, and a heavy duty drag chain running on precision ground steel guides for vibration free operation with larger panels and thicker edging.
