SCM Minimax E 10

Manual Shaped Edgebander

Full details of SCM Minimax E 10

Configure your machine

Additional options

Power *

- +

more information

  • Features
    • External and internal radius edging
    • Hot-melt glue pot
    • Anti-scratch work surface
    • High rigidity and stability steel monoblock base
    • Shear device for rolled edges complete with roll-holder plate
    • Glue application of edging material by means of a powered glue spreading roller
    • One idle pressure roller
    • Start/stop cycle pedal
  • Description

    The SCM Minimax E 10 is a manually fed hot melt edgebander for working with shaped panels. Edging can be applied to both external and internal radii. The teflon-coated glue pot, positioned under the work table features with continuous glue circulation avoids burning of the adhesive. Adjustable glue delivery moderates the quantity of the glue to be applied on the edge. The special anti-scratch phenolic multilayer work table with modular holes and panel supports gives a stable worksurface for the operator.

  • Specification
    • Edge thickness, pre-cut strips, min. - max. 0.4 - 3 mm
    • Edge thickness with shear, 80 mm height 5 mm
    • Edge thickness with shear, 50 mm height 5 mm
    • Edge thickness with shear, 45 mm height 5 mm
    • Edge height 10- 84 mm
    • Panel thickness, min. - max. 8 - 80 mm
    • Panel length, min. 210 mm
    • Panel width, min. 50 mm
    • Internal radius with 0.4 mm edge, min. 25 mm
    • External radius with 0.4 mm edge, min. 5 mm
    • Feed speed(s) 4 & 8 m/min
    • Compressed air 6.5 - 8 bar
    • Power 3 phase
  • Literature
  • Important information

    Our suppliers have a policy of continuous product development and improvement, specifications are therefore subject to change without notice. We can accept no liability for discrepancies in specifications or illustrations contained in our publications or the publications of our suppliers.
