Phillipson CBS1

Contour Belt Sander

To get a quote or for further information please contact us on:

Email us
  • Features

    • Manufactured in the UK
    • Supplied with 4 contour bars (15, 30, 40, 50 mm)
    • Grooved table for added control
    • Spring loaded belt tensioner
    • Accurtilt vernier measurement to table positin and zero lock
    • Extreme accuracy
    • Suitable for a range of work sizes
    • No-volt release and overload protection
    • Foot operated stop
  • Description

    The CBS1 contour belt sander offers quick and accurate sanding of almost any contour. Abrasive belts travel at selected speeds over rigidly supported metal bars to facilitate sanding of the workpiece. For full versitality the Phillipson CBS1 is supplied with 4 contour bars (15, 30, 40 & 50mm wide). These contours bars are dual sided with both flat and rounded radius profiles. The large work table is infinitely adjustable and inclines 45 degrees both ways with a spring lock at 0 degrees.

  • Specification

    • Maximum sanding height 400 mm
    • Belt speed 15 & 30 m/sec
    • Belt length 2710 mm
    • Table dimensions 700 x 700 mm
    • Table height 1000 mm
    • Table tilt 45ยบ
    • Extraction outlet diameter 125 mm
    • Nett weight 380 kg
    • Overall dimensions 800 mm (L) x 800 mm (W) x 1000 mm (H)
    • Motor 1.3 kW
    • Power 3 phase
  • Literature

  • Disclaimer

    Our suppliers have a policy of continuous product development and improvement, specifications are therefore subject to change without notice. We can accept no liability for discrepancies in specifications or illustrations contained in our publications or the publications of our suppliers.
